Ratel 4

Ratel 4 Sleeper







Give your family a home in the wild, with South Africa’s most reliable offroad caravan. Wherever you set up camp, they will feel that they belong.

The ‘go-big-or-go-home’ Bush Lapa caravan.
Supreme luxury.
Set up camp in under 15 minutes.
Sleeps 4 adults.
1040kg dry weight
3CR12 Stainless steel body and chassis with a 1 year warranty.
GVM 1800 kg
Departure angle of 22°
Comes standard with the fuss-free Bush Wing® awning including complete set of sides, and spacious kitchen layout, additional fridge drawer with loads of storage space, gas geyser, shower wing under awning and lots more.




Specifications






General Specifications

Dry weight: 1140kg
Total length: 5100mm
Total height: 2150mm
Total height to top of Bush Wing: 2250mm
Head room: 1980mm
Total width: 1970mm
Ground clearance (axle): 350mm
Departure angle: 22°
Solid beam axle with leaf springs and shock absorbers: 1800kg
GVM: 1800kg
Loading Capacity: 660kg
Beds: 2 x double beds
Sleeps: 4 adults
Stainless steel body and chassis: Yes
Aluminium interior and doors: Yes
Micro dotted: Yes
1 year guarantee on material and workmanship: Yes

Standard Features

Bush Wing Awning: 90° x 270° (with full set of sides and draft skirt)
3 x 15″ wheels, 6 stud, steel epoxy rims with spare wheel: Yes
Kitchen with stainless steel working table: Yes
Stabilizers, Jacks, High-Lift Jacks: Yes – 2
Wheel spanner, lockable spare wheel: Yes
Double cupboards: 10
Canvassing in front of rear storage units: Yes
Double mattresses: 2
Side bed with tents: Yes
Aluminium nose box: Yes
Jerry cans: 2
Deep cycle battery: 1
Kitchen dual LED light: 3
LED lights: 3
Hella points 12V: 3
Anderson fridge points: 1
220V caravan inlet plug: Yes
Charging system: Yes
Charging system from vehicle: Yes
Mud flaps: Yes
Fire extinguisher: Yes
Aluminium kitchen drawers: Yes
Cast iron burner: 2 plates
Water tank: 150 litre
Direct gas connection: Yes
Crockery set: Yes
Front bed with tent: Yes
Jockey wheel: Yes
Gas geyser: Yes
Warm and cold water at wash basin and shower: Yes
Dual entry doors: Yes
Shower cubicle: Yes
Wash basin: Yes
Jockey wheel out of the way bracket: Yes



Optional Extras

Mosquito net at door
140W solar panel with controller and aluminium roof rack
220V caravan extension lead for mains 10m
National Luna, Engel and Sno-Master fridges on request
Bearing kit
Other axle than standard
Extra battery cover box with fixing brackets (for second battery)
Second battery (deep cycle)
Extra LED lights
Gas bottle brackets
Gas bottles (filled)
Mag wheels
Inside floor carpet
Inverter 300-500W
1200 x 600mm loose-standing aluminium table with fold in legs and bag
Stone protector
Bicycle rack towbar (excluding ball)
Aluminium toolbox between nose boxes (in jerry can compartment)
Mud flap stone protector for chassis
