Discoverer Xtreme 4×4 – Isuzu Motorhome

The Discoverer Xtreme 4×4 – Isuzu is a purpose-built off-road motorhome designed for travellers who venture beyond conventional touring routes. Built on the dependable Isuzu 4×4 platform, it combines proven durability with practical functionality, making it an excellent choice for remote expeditions and extended overland adventures.

Engineered to handle demanding terrain, the Discoverer Xtreme features selectable four-wheel drive, heavy-duty suspension and impressive payload capacity for carrying essential equipment and supplies. Its robust construction provides the confidence to tackle challenging conditions while maintaining comfort throughout every journey.

Whether you’re exploring remote wilderness areas, gravel passes or rugged African landscapes, the Discoverer Xtreme 4×4 – Isuzu delivers the reliability, capability and freedom to travel wherever adventure calls.

Highlights

• Purpose-built Isuzu 4×4 off-road motorhome
• Selectable four-wheel drive system
• Heavy-duty turbo diesel engine
• 5-speed manual transmission
• High and low-range transfer case
• Excellent payload capacity for extended expeditions
• 100L fuel tank
• Heavy-duty leaf spring suspension
• Built for remote overland travel
• Designed for demanding off-road adventures

Specifications

Engine: Isuzu 4HK1-TCN

Configuration: 4-Cylinder Turbo Diesel, Intercooled

Displacement: 5,193 cc

Power: 110 kW @ 2,600 rpm

Torque: 404 Nm @ 1,500–2,600 rpm

Emissions: Euro II (SA Specification)

Drivetrain: Selectable 4×4

Transfer Case: High 1.00:1 / Low 1.84:1

Front Hubs: Manual Locking

Transmission: Isuzu MYY5T 5-Speed Manual

PTO Provision: Gearbox Mounted

Gross Vehicle Mass (GVM): 6,200 kg

Gross Combination Mass (GCM): 9,500 kg

Kerb Mass: Approx. 3,060 kg

Payload: Approx. 3,140 kg

Front Axle Rating: 2,800 kg

Rear Axle Rating: 6,600 kg

Wheelbase: 3,395 mm

Overall Length: 5,985 mm

Overall Width: 1,995 mm

Overall Height: 2,265 mm

Ground Clearance: Approx. 235 mm

Turning Circle: 6,450 mm (Kerb to Kerb)

Front Suspension: Semi-Elliptic Leaf Springs

Rear Suspension: Semi-Elliptic Leaf Springs

Brakes: Drum Brakes Front & Rear with ABS

Fuel Tank Capacity: 100 Litres

Tyres: 10.00 R17.5

Why Choose the Discoverer Xtreme 4×4 – Isuzu?

The Discoverer Xtreme 4×4 – Isuzu is built for travellers who demand reliability and capability in challenging environments. Combining the proven Isuzu 4×4 platform with rugged engineering and impressive load-carrying capacity, it provides the confidence to explore remote destinations while enjoying the freedom of true off-road adventure.
